Description
| Display | System Specification | Camera |
| Size – 10.1 inches | Processor – Intel Pentium N4200 1.1GHz (up to 2.5GHz) | Front Camera – 2MP Front Camera |
| Resolution – 1920×1200 | Memory – 4GB LPDDR4 8GB LPDDR4 (Optional) |
Rear Camera – 8MP Rear Camera with auto-focus and LED light |
| Type – Projected Capacitive Multi Touch | Storage – 128GB SSD Additional storage available with micro SDXC card slot 256GB SSD (Optional) 512GB SSD (Optional) |
|
| Panel Brightness – 800.0 nits | Smart Card Reader – Add-on Smart Card Reader (Optional) | |
| Contrast Ratio – 800:1 | Security – Trusted Platform Module (TPM) 2.0 Kensington Lock |
|
| View Angles – 85,85,85,85 | Operating System – Windows 10 IoT Enterprise (64 bit) | |
| Bonding – Optical Bonding for Sunlight Viewability | WLAN – Support | |
| Viewability – Anti-Glare touch treatment | BT – Support | |
| WWAN – 4G LTE (Optional) | ||
| GNSS – GPS, GLONASS | ||
| RFID – HF RFID 13.56 MHz reader (Optional) add-on UHF RFID Reader (Optional) |
||
| Sensors – Light sensor/ G-sensor / Gyro | ||
| Mechanical | IO Ports | Environment |
| Dimension – 271.9 x 197.3 x 19.5 mm | USB Port – 1 x USB 3.0 (Type A), 1 x USB 3.0 (Type C) | Operating Humidity – 10% to 90% RH, non-condensing |
| Weight – 1.2 kg (2.65 lbs) with standard battery, 1.4 kg (3.1 lbs) with optional high capacity battery |
Video – 1 x Micro HDMI (Optional) | Operating Temperature – -20°C to 60°C |
| Cooling System – Fanless design | Audio – 1 x Audio combo 3.5mm audio combo jack (Mic in or Line Out) Dual Digital Mic With Noise Cancellation Dual Speaker |
Storage Temperature – -30°C to 70°C (-22°F to 158°F) |
| SD Card Slot – 1 x Micro SDXC slot | Shock – MIL-STD-810G Method 516.6 Procedure I | |
| SIM Card Slot – 1 x Micro SIM card slot | Vibration – MIL-STD-810G Method 514.6 Procedure I | |
| Expansion Port – 1 x Expansion connector for USB 2.0/ Full RS232 (Optional) | Drop – MIL-STD-810G Method 516.6, 4 ft | |
| Indicator – 4x LED Indicator for Power, Battery, HDD, RF status | IP rating – IP65 | |
| Docking Connector – 1 x 19-pin docking connector | ||
| Certification | Security Function | Control |
| Certification – CE, FCC, UL, PTCRB, Verizon | SOTI MobiControl – SOTI MobiControl Compliance | Button – 1 x Power, 1 x Home, 2 x Volume, 2 x Programmable Function Keys |
| Kensington Lock – Kensington Lock Support | ||
| Power | Accessory | Barcode Scanner |
| Battery – Hot-swappable 7.7V, typ. 5900 mAh Li-Polymer Battery (2S1P) 7.4V, typ. 10280 mAh Li-Polymer Battery (2S2P, optional) |
Accessory – Adapter and Power Cord Capacitive Stylus Standard Battery |
Barcode Scanner – 1D/2D barcode reader (Optional) |
| Battery Operating Time – Standard. Battery: 9 hours High Capacity Battery: 16 hours |
Optional Accessory – Desk Dock (Optional) Vehicle Dock (without VGA output) (Optional) Vehicle Cradle (Optional) Battery Charger (Optional) Smart Card Reader (Optional) High Capacity Battery (Optional) Hand Strap (Optional) VESA Mount Kit (Optional) Shoulder Strap (Optional) Carry Bag (Optional) Vehicle Charger (Optional) |
|
| Power Rating – 19V DC | ||
| Adapter – 100-240V, 50-60Hz / 19V DC |
